SPECIFICATIONS

Brake Type: Disc Brake Mechanical

Department: Unisex Adults

Folded: No

Frame Material: Aluminum Alloy

Gear Change Mechanism: Derailleur Gears

Max Speed: 30-50km/h

Maximum Speed: 28mph

Model Number: Q20MINI

Motor: Brushless

Number of Speeds: 7 Speed

Power Source: Lithium Battery

Power Supply: Lithium Battery

RIDSTAR Moddel: Q20

Range per Power: 31 - 60 km

Style: Standard Type

Suspension Type: Full Suspension

Tire Type: Fat Tires

Voltage: 48V

Wattage: > 500w

Wheel Size: 20“

Basic parameters (MINI Version)
Expanded size: length 1710*width 850*height 1080mm
Wheelbase: 1180mm
Actual weight: 42kg
Mode: pure electric, electric assist, pedal
Front fork: hydraulic front fork
Braking system:Front and rear mechanical disc brakes
Transmission system: rear drive
Tire size: 20*4.0
Maximum speed ≤40km/h
Endurance 55km
Slope <30°
Load weight≤150kg
Motor type: DC brushless high-speed motor
Rated voltage 48V
Main technical parameters of charging
Output power 2A
Charging time 4-6H
Lithium battery parameters
Battery type: 18650 lithium battery
Capacity 15AH
The main parameters of the controller
Undervoltage protection: 39V
Overcurrent protection: 28A
