SPECIFICATIONS

Capacity: 200Ah

Battery Cells:Lithium Iron Phosphate(LiFePO4) battery

Nominal voltage: 12.8V

Rated voltage: 12V

Max Protection Voltage: 14.6V

End Voltage: 10V

Size:522*240*218mm

Weight: 19.5KG

Certificate: CE ROHS MSDS UN38.3

Upgrade Parts/Accessories: Grade A

Voltage Protection Board(BMS): Yes

Cycles Life:7000Cycles

Max Charge Current: 0.5C

Max Continuous Current: 1C

Instantaneous discharge current: 2C

Workingtemperature : -20 ~ 60 ℃

Charge temperature: 0-45℃

Terminal: Button terminal(can be charged and discharged)

Warranty: 2 years

Operating temperatures: Standard 0°C~45°C(32°F~113°F), Discharge -20°C~65°C(-4°F~149°F),Storage -20°C~45°C(-4°F~113°F)

Parcel includes：

1. A LiFePO4 Energy Storage Battery

2. A product instruction manual

Series/Parallel

not only could series or parallel, but also could series/parallel more than other brands. 12v lithium batteries series to 24v/36v/48v/60/72v battery, one battery various use.

Upgraded BMS -  newest lifepo4 battery used high version Series BMS panel, better performance in series/parallel. Also it has overcharge, overdischarge, overcurrent, short circuit low/high temperature cut-off protection. More easy to use and lower defective rate.

1. Lithium Iron Phosphate -   deep cycle lithium ion batteries have unlimited mounting capability, exceptional longevity, and are more cost effective.

2. LIGHTWEIGHT AND VERSATILE - At the same capacity battery, MOSEWORTH's lifepo4 battery weighs only 1/3 of the lead-acid battery.With no acid in the battery, you're able to safely mount in any position. This makes li-ion batteries perfect for marine, RV, campers, golf cart, off-road and off-grid applications!

3. GREEN ENERGY BATTERIES - Made from 100% safe, nontoxic, renewable energy, MOSEWORTH Batteries last for more cycles and can be charged and discharged repeatedly (and charge faster than any other battery). We make our renewable, sustainable green energy batteries because they’re simply better than anything else out there, including other green batteries.
